TM4 SUMO MD HV2800-6P
TM 4 SUMO MD combines an outer-rotor permanent-magnet motor and high-voltage inverter for commercial vehicles and buses. It interfaces directly with standard axles without a separate gearbox.
The 800 V HV 2800-6 P variant uses an L 2 casing and CO 200 inverter. At 650 VDC and 45°C, ratings are 300 kW peak and 180 kW continuous power, with 2,860 Nm peak and 1,050 Nm continuous torque. Operating voltage is 300–800 VDC and maximum speed 3,500 rpm. Protection is IP 67/IP 6 K 9 K, and maximum coolant inlet temperature 65°C.
